IX5010 - SecureEdge Wi-Fi
$925.00
Key features
- Secure OS (IEC-62443-4-2 certified)
- Integrated firewall to isolate factory network from internet
- Registration with IXON Cloud in just 1 minute
- Fully configurable from the cloud
- Wide protocol support: OPC-UA, Modbus TCP, Siemens S7, EtherNet/IP, MELSEC and plain-text TCP
- VPN sessions encrypted using SSL/TLS protocol and authenticated using x509 SSL certificates
- Optional OT-port for network segmentation
Specifications
| Wi-Fi Client and Hotspot | Yes |
| 4G Global | No |
| GPS | No |
| Ethernet ports | 4 x LAN, 1 x WAN (all 1 Gbps) - 1 LAN port can be configured as second WAN port |
| CPU | Quad-Core ARM Cortex-A53, max 1.8 GHz |
| Memory | 1GB LPDDR4 |
| Storage | 32GB eMMC in pSCL mode for reliability, with 5GB user space. |
| Expandable storage | No |
| Temperature | -25°C to 60°C |
| VPN speed (TCP)/UDP) | Approx. 30 Mbit/s |
| Docker Apps | No |
| Touchscreen | 0.96" monochrome OLED display, capacitive touch panel |
| Other software features | Remote access via USB-over-IP, local NTP server to keep time synced, local API for status and configuration from PLC |
| Certifications | CE, FCC, cULus, Verizon |
| I/O | Configurable pin for Input or Output |
| Other hardware | USB 2.0 (type C), eSIM, TPM 2.0, Nano sim card (4FF) |
| Size | 112x101x31 mm (H x D x W) |
